Grades |
XXX |
GE |
LE |
G-5,G-9 |
G-10 |
G-11 |
|
Features
|
Electrical insulation, high humidity resistance, good dimensional stability, good machining.
|
Good acid resistance, low voltage, low frequency electrical performance, high impact strength, good mechanical properties.
|
High mechanical and electrical strength, good appearance, good machining qualities, moisture resistance.
|
High mechanical strength, high arc and heat resistance, self extinguishing, excellent electrical properties under dry and humid conditions. |
High flexural, impact and
bond strength
at room
temperatures, good electrical properties
under dry and humid
conditions. |
High mechanical strength at temperatures up to 150°C, self extinguishing, retains 50% of its flexural strength at elevated temperatures. |
|
Diameters
Sizes other than standard can be furnished on request
|
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
5/16
3/8
7/16
1/2
|
9/16
5/8
3/4
7/8
1"
1 1/8
1 1/4
1 3/8
1 1/2
|
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8 |
1"
1 1/8
1 1/4
1 3/8
1 1/2
1 5/8
1 3/4
2"
2 1/4
2 1/2
2 3/4
3"
3 1/4
3 1/2
3 3/4
4" |
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8 |
1"
1 1/8
1 1/4
1 3/8
1 1/2
1 5/8
1 3/4
2"
2 1/4
2 1/2
2 3/4
3"
3 1/4
3 1/2
3 3/4
4" |
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
5/16
3/8
7/16
1/2 |
9/16
5/8
3/4
7/8
1"
1 1/8
1 1/4
1 3/8
1 1/2
1 5/8
1 3/4
2" |
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8 |
1"
1 1/8
1 1/4
1 3/8
1 1/2
1 5/8
1 3/4
2"
2 1/4
2 1/2
2 3/4
3"
3 1/4
3 1/2
3 3/4
4" |
1/16
3/32
1/8
5/32
3/16
7/32
1/4
9/32
5/16
3/8
7/16
1/2 |
9/16
5/8
3/4
7/8
1"
1 1/8
1 1/4
1 3/8
1 1/2
1 5/8
1 3/4
2" |
|
Tolerance |
All diameters +/- .001. Closer tolerances quoted on request.
|
1/16" to 1 1/4" diameter inclusive +/- .001. 1 3/8" diameter and over +/- .003. Closer tolerance quoted on request. |
1/16" to 1 1/4" diameter inclusive +/- .001. 1 3/8" diameter and over +/- .003. Closer tolerance quoted on request. |
1/16" to 1 1/4" diameter inclusive +/- .001. 1 3/8" diameter and over +/- .003. Closer tolerance quoted on request. |
1/16" to 1 1/4" diameter inclusive +/- .001. 1 3/8" diameter and over +/- .003. Closer tolerance quoted on request. |
1/16" to 1 1/4" diameter inclusive +/- .001. 1 3/8" diameter and over +/- .003. Closer tolerance quoted on request. |
|
Color |
Natural. Black is often available at no additional charge. |
Natural. Black is often available at no additional charge. |
Natural. Black is often available at no additional charge. |
Natural color only. |
Natural color only. |
Natural color only. |
|
Length |
4 foot nominal. Special lengths quoted on request.
|
4 foot nominal. Special lengths quoted on request.
|
1/2" diameter and under - 4 foot nominal. Over 1/2" diameter - 4 foot nominal. Special lengths quoted on request. |
4 foot nominal. Special lengths quoted on request.
|
4 foot nominal. Special lengths quoted on request.
|
4 foot nominal. Special lengths quoted on request.
|
|
Specifications |
Grade XXX phenolic rod meets or exceeds all requirements of Federal Specifications Mil-I-24768. Type PBE, as revised. |
Grade CE phenolic rod meets or exceeds all requirements of Military Specification Mil-I-24768, Type FBG. |
Grade LE phenolic rod meets or exceeds all requirements of Military Specification Mil-I-24768, Type FBE. |
Meets or exceeds all requirements of Military Specification Mil-I-24768, Type GME |
Meets or exceeds all requirements of Military Specification Mil-I-24768, Type GEE |
Meets or exceeds all requirements of Military Specification Mil-I-24768, Type GEB. |
